規格 Specification
| 屬性 | 參數 |
|---|---|
| Dimension | 92 x 236 (mm) |
| Application | FB3 or FB6 |
| Feature | Safety isolation design; 12V Lead-Acid battery charger, Pedal start power, High Console power |
| Input | 25VAC ~ 270VAC |
| DC Output | '+14.5V ±2.5V 1A (max) or External power input 3A (Battery or DC Adaptor ) |
| Resistance Command | PWM Signal (40Hz ~ 200Hz) |
| Brake Current | 0 ~ 3A max |
| RPM Signal | Open collector output (Detects from generator) Detects from pedal signal |
